6-40
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C4622 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4623 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4626 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C4801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4802 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C4803 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
! C4804 1-115-464-91 CERAMIC CHIP 0.0022uF 10% 630V
< CONNECTOR >
CN4501 1-766-350-21 CONNECTOR, FFC/FPC 20P
CN4602 1-573-356-21 CONNECTOR, FFC/FPC 16P
< DIODE >
D4601 8-713-102-80 DIODE 1T369-01-T8A
D4602 8-719-043-70 DIODE MA6S121-(TX)
! D4802 8-719-056-49 DIODE 1SS370(TE85L)
< IC >
IC4501 8-759-546-65 IC CXA8115AR-T4
IC4502 8-759-364-05 IC M62376GP-65AD
IC4601 8-759-097-75 IC MB3789PFV-G-BND-ER
IC4602 8-752-392-33 IC CXD2458AR-T4
IC4603 8-759-580-26 IC NJM2130F(TE2)
< COIL >
L4501 1-414-754-11 INDUCTOR 10uH
L4502 1-414-756-11 INDUCTOR 47uH
L4601 1-414-756-11 INDUCTOR 47uH
L4602 1-414-756-11 INDUCTOR 47uH
L4603 1-412-949-21 INDUCTOR 6.8uH
L4801 1-412-031-11 INDUCTOR CHIP 47uH
L4802 1-412-029-11 INDUCTOR CHIP 10uH
< FLUORESCENT INDICATOR >
! ND4801 1-517-414-71 FLUORESCENT TUBE (0.55 INCH)
< TRANSISTOR >
Q4601 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q4602 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q4603 8-729-045-84 TRANSISTOR RN2105F(TPL3)
! Q4801 8-729-039-24 TRANSISTOR FX216-TL1
< RESISTOR >
R4501 1-216-864-11 METAL CHIP 0 5% 1/16W
R4503 1-216-837-11 METAL CHIP 22K 5% 1/16W
R4504 1-216-837-11 METAL CHIP 22K 5% 1/16W
R4505 1-216-839-11 METAL CHIP 33K 5% 1/16W
R4509 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4510 1-216-839-11 METAL CHIP 33K 5% 1/16W
R4511 1-216-840-11 METAL CHIP 39K 5% 1/16W
R4512 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4513 1-216-840-11 METAL CHIP 39K 5% 1/16W
R4514 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4515 1-216-839-11 METAL CHIP 33K 5% 1/16W
R4516 1-216-841-11 METAL CHIP 47K 5% 1/16W
R4517 1-216-840-11 METAL CHIP 39K 5% 1/16W
R4518 1-216-809-11 METAL CHIP 100 5% 1/16W
R4519 1-216-809-11 METAL CHIP 100 5% 1/16W
R4521 1-216-809-11 METAL CHIP 100 5% 1/16W
R4524 1-218-907-11 RES,CHIP 330K 0.50% 1/16W
R4525 1-218-877-11 RES,CHIP 18K 0.50% 1/16W
R4602 1-216-840-11 METAL CHIP 39K 5% 1/16W
R4604 1-216-835-11 METAL CHIP 15K 5% 1/16W
R4605 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4606 1-218-901-11 RES,CHIP 180K 0.50% 1/16W
R4607 1-216-839-11 METAL CHIP 33K 5% 1/16W
R4608 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R4609 1-216-864-11 METAL CHIP 0 5% 1/16W
R4610 1-216-821-11 METAL CHIP 1K 5% 1/16W
R4611 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4612 1-216-842-11 METAL CHIP 56K 5% 1/16W
R4615 1-216-864-11 METAL CHIP 0 5% 1/16W
R4616 1-218-887-11 RES,CHIP 47K 0.50% 1/16W
R4617 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4618 1-216-850-11 METAL CHIP 270K 5% 1/16W
R4619 1-216-864-11 METAL CHIP 0 5% 1/16W
R4620 1-216-838-11 METAL CHIP 27K 5% 1/16W
R4621 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4622 1-216-847-11 METAL CHIP 150K 5% 1/16W
R4623 1-216-841-11 METAL CHIP 47K 5% 1/16W
R4624 1-216-848-11 METAL CHIP 180K 5% 1/16W
R4625 1-216-840-11 METAL CHIP 39K 5% 1/16W
R4626 1-216-851-11 METAL CHIP 330K 5% 1/16W
R4627 1-216-850-11 METAL CHIP 270K 5% 1/16W
R4629 1-216-837-11 METAL CHIP 22K 5% 1/16W
R4630 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4634 1-216-809-11 METAL CHIP 100 5% 1/16W
R4635 1-216-841-11 METAL CHIP 47K 5% 1/16W
R4636 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4637 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4801 1-216-839-11 METAL CHIP 33K 5% 1/16W
< TRANSFORMER >
! T4801 1-426-848-51 TRANSFORMER, INVERTER
************************************************************
A-7073-838-A VF-129(N) BOARD, COMPLETE
(TRV103/TRV110/TRV110P/TRV203/TRV210/TRV310/TRV310P)
**********************
A-7073-855-A VF-129(P) BOARD, COMPLETE
(TRV110E/TRV210E/TRV310E)
*************************
(Ref.No.:6000 Series)
< CAPACITOR >
C901 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C902 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C903 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C904 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C905 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C906 1-162-638-11 CERAMIC CHIP 1uF 16V
C907 1-104-563-11 FILM CHIP 0.1uF 5% 16V
C908 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C909 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
! C910 1-162-625-11 CERAMIC CHIP 0.0047uF 5% 50V
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VF-126 VF-129
