6-24
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R5685 1-216-841-11 METAL CHIP 47K 5% 1/16W
(EXCEPT:TRV310/TRV310P)
R5685 1-216-842-11 METAL CHIP 56K 5% 1/16W
(TRV310/TRV310P)
R5686 1-216-841-11 METAL CHIP 47K 5% 1/16W
(EXCEPT:TRV310/TRV310P)
R5686 1-216-842-11 METAL CHIP 56K 5% 1/16W
(TRV310/TRV310P)
R5688 1-216-864-11 METAL CHIP 0 5% 1/16W
R5692 1-216-851-11 METAL CHIP 330K 5% 1/16W
(EXCEPT:TRV110E:AEP,UK,EE,NE,RU)
R5692 1-216-854-11 METAL CHIP 560K 5% 1/16W
(TRV110E:AEP,UK,EE,NE,RU)
R5694 1-216-833-11 METAL CHIP 10K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5694 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5695 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5696 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT:TRV310/TRV310P)
R5697 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV310/TRV310P)
R5698 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV310/TRV310P)
R5703 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5704 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5705 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5706 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R5707 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5708 1-216-810-11 METAL CHIP 120 5% 1/16W
R5709 1-216-817-11 METAL CHIP 470 5% 1/16W
R5710 1-216-816-11 METAL CHIP 390 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5710 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5801 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5802 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5803 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5804 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5805 1-216-838-11 METAL CHIP 27K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5806 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5807 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5808 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5811 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5812 1-216-855-11 METAL CHIP 680K 5% 1/16W
(TRV103/TRV110/TRV110E/TRV110P)
R5900 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5901 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5902 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5903 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5904 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5905 1-216-838-11 METAL CHIP 27K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5906 1-216-855-11 METAL CHIP 680K 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5907 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5909 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
R5911 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
< SWITCH >
S5801 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT (+))
(TRV103/TRV110/TRV110E/TRV110P)
S5802 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT (–))
(TRV103/TRV110/TRV110E/TRV110P)
S5803 1-692-088-41 SWITCH, TACTILE (VOLUME (+))
(TRV103/TRV110/TRV110E/TRV110P)
S5804 1-692-088-41 SWITCH, TACTILE (VOLUME (–))
(TRV103/TRV110/TRV110E/TRV110P)
S5900 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT (+))
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
S5901 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT (–))
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
S5902 1-692-088-41 SWITCH, TACTILE (VOLUME (+))
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
S5903 1-692-088-41 SWITCH, TACTILE (VOLUME (–))
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
< TRANSFORMER >
! T5701 1-431-753-11 TRANSFORMER, INVERTER
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
! T5701 1-433-452-11 TRANSFORMER, INVERTER
(TRV103/TRV110/TRV110E/TRV110P)
************************************************************
A-7073-868-A PJ-95 BOARD, COMPLETE
(TRV103/TRV110/TRV110E:E,HK,AUS,CN,JE/TRV110P)
*********************
A-7073-919-A PJ-98 BOARD, COMPLETE (TR7000)
*********************
A-7073-924-A PJ-96 BOARD, COMPLETE
(TRV203/TRV210/TRV210E:CN/TRV310/
TRV310E:E,HK,AUS,CN,JE/TRV310P/TRV315)
*********************
A-7073-941-A PJ-95(IM) BOARD, COMPLETE
(TRV110E:AEP,UK,EE,NE,RU)
*************************
(Ref.No.:7000 Series)
A-7073-954-A PJ-96(IM) BOARD, COMPLETE
(TRV210E:AEP,UK/TRV310E:AEP,UK)
*************************
(Ref.No.:8000 Series)
A-7073-976-A PJ-98(IM) BOARD, COMPLETE
(TR7000E/TR7100E)
*************************
(Ref.No.:9000 Series)
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
PD-105/106 PJ-95/96/98
