6-20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1-658-213-11 FP-355 FLEXIBLE BOARD
********************
(Ref.No.:20000 Series)
< DIODE >
D001 8-719-988-42 DIODE GL453
************************************************************
A-7073-869-A MA-354(I) BOARD, COMPLETE
(TRV103/TRV110/TRV110E/TRV110P)
*************************
(Ref.No.:7000 Series)
A-7073-920-A MA-357(I) BOARD, COMPLETE
(TR7000/TR7000E/TR7100E)
*************************
(Ref.No.:9000 Series)
A-7073-925-A MA-355(I) BOARD, COMPLETE
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
*************************
(Ref.No.:8000 Series)
< CAPACITOR >
C300 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C304 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C305 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C308 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C309 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C310 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C311 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C312 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C313 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C314 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C315 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C316 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C318 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C319 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C320 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C321 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C322 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C323 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C324 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C325 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C326 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C327 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C328 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C329 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C330 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C331 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C332 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C343 1-115-156-11 CERAMIC CHIP 1uF 10V
C344 1-115-156-11 CERAMIC CHIP 1uF 10V
C345 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C346 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C347 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C348 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C349 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C350 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C351 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
< CONNECTOR >
CN300 1-774-635-21 CONNECTOR, FFC/FPC 10P
CN301 1-778-283-11 CONNECTOR, FFC/FPC 4P
CN302 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
CN303 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
CN304 1-779-335-21 CONNECTOR, FFC/FPC 22P
< DIODE >
D300 8-719-073-03 DIODE MA8082-(K8).S0
D301 8-719-073-03 DIODE MA8082-(K8).S0
D302 8-719-073-01 DIODE MA111-(K8).S0
D303 8-719-062-16 DIODE 01ZA8.2(TPL3)
D304 8-719-062-16 DIODE 01ZA8.2(TPL3)
D305 8-749-060-65 DIODE DCC3810
D306 8-719-061-86 DIODE DCR2810
D308 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D309 8-719-073-01 DIODE MA111-(K8).S0
< FUSE >
! F300 1-533-874-11 FUSE, MICRO (200mA/24V)
< IC >
IC300 8-759-494-54 IC AN2900FH-EB
IC301 8-749-012-83 IC RS-180-T
< COIL >
L300 1-414-757-11 INDUCTOR 100uH
L301 1-414-757-11 INDUCTOR 100uH
L302 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q302 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
Q303 8-729-420-50 TRANSISTOR UN5215-(TX)
< RESISTOR >
R300 1-414-228-11 INDUCTOR CHIP 0UH
R301 1-414-228-11 INDUCTOR CHIP 0UH (Note)
R302 1-414-228-11 INDUCTOR CHIP 0UH (Note)
R303 1-216-835-11 METAL CHIP 15K 5% 1/16W
R304 1-216-839-11 METAL CHIP 33K 5% 1/16W
R305 1-216-836-11 METAL CHIP 18K 5% 1/16W
R306 1-216-835-11 METAL CHIP 15K 5% 1/16W
R307 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R308 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R309 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R310 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R311 1-216-821-11 METAL CHIP 1K 5% 1/16W
R312 1-216-821-11 METAL CHIP 1K 5% 1/16W
R313 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R314 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MA-354/355/357
Note : Inductors are mounted to the location where R301, R302
are printed.
FP-355
