6-25
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< CAPACITOR >
C101 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C112 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
C113 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
< CONNECTOR >
CN101 1-785-685-21 CONNECTOR, FFC/FPC (ZIF) 14P
< DIODE >
D101 8-719-062-16 DIODE 01ZA8.2(TPL3)
D102 8-719-062-16 DIODE 01ZA8.2(TPL3)
D103 8-719-062-16 DIODE 01ZA8.2(TPL3)
D104 8-719-073-03 DIODE MA8082-(K8).S0
D105 8-719-062-16 DIODE 01ZA8.2(TPL3)
D106 8-719-062-16 DIODE 01ZA8.2(TPL3)
< JACK >
J101 1-537-747-21 TERMINAL BOARD (S VIDEO/VIDEO/AUDIO)
< COIL >
L101 1-414-072-11 INDUCTOR 1uH
L102 1-216-295-91 SHORT 0 (Note 1)
(EXCEPT:TRV110E:AEP,UK,EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L102 1-412-963-11 INDUCTOR 100uH
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L103 1-216-295-91 SHORT 0 (Note 1)
(EXCEPT:TRV110E:AEP,UK,EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L103 1-412-963-11 INDUCTOR 100uH
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L104 1-216-295-91 SHORT 0 (Note 1)
(EXCEPT:TRV110E:AEP,UK,EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L104 1-412-963-11 INDUCTOR 100uH
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L105 1-216-295-91 SHORT 0 (Note 1)
(EXCEPT:TRV110E:AEP,UK,EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
L105 1-412-963-11 INDUCTOR 100uH
(TRV110E:AEP,UK.EE,NE,RU/TRV210E:AEP,UK/
TRV310E:AEP,UK/TR7000E/TR7100E)
< TRANSISTOR >
Q101 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q102 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R101 1-500-283-11 INDUCTOR CHIP 0UH (Note 2)
R102 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R103 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R104 1-216-820-11 METAL CHIP 820 5% 1/16W
R105 1-216-836-11 METAL CHIP 18K 5% 1/16W
R106 1-500-283-11 INDUCTOR CHIP 0UH (Note 2)
R107 1-500-283-11 INDUCTOR CHIP 0UH (Note 2)
R108 1-216-821-11 METAL CHIP 1K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
R110 1-500-283-11 INDUCTOR CHIP 0UH
R111 1-414-228-11 INDUCTOR CHIP 0UH (Note 2)
R112 1-414-228-11 INDUCTOR CHIP 0UH (Note 2)
R113 1-414-228-11 INDUCTOR CHIP 0UH (Note 2)
R114 1-414-228-11 INDUCTOR CHIP 0UH (Note 2)
R115 1-414-228-11 INDUCTOR CHIP 0UH (Note 2)
************************************************************
A-7073-867-A SE-86 BOARD, COMPLETE
(TRV103/TRV110/TRV110E/TRV110P)
*********************
(Ref.No.:7000 Series)
A-7073-918-A SE-89 BOARD, COMPLETE
(TR7000/TR7000E/TR7100E)
*********************
(Ref.No.:9000 Series)
A-7073-923-A SE-87 BOARD, COMPLETE
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
*********************
(Ref.No.:8000 Series)
< CAPACITOR >
C601 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C602 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C603 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C604 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C607 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
C608 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
C609 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
C610 1-110-666-11 ELECT CHIP 22uF 20% 6.3V
C611 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
C612 1-110-666-11 ELECT CHIP 22uF 20% 6.3V
Note 1: Resistors are mounted to the location where L102, L103,
L104, L105 are printed.
Note 2: Inductors are mounted to the location where R101, R106,
R107, R111-115 are printed.
PJ-95/96/98 SE-86/87/89
