6-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7073-866-A DD-117(V) BOARD, COMPLETE
(EXCEPT:TRV315/TR7000/TR7000E/TR7100E)
*************************
A-7073-917-A DD-117 (C) BOARD, COMPLETE
(TR7000/TR7000E/TR7100E)
**************************
A-7073-922-A DD-117(VC) BOARD, COMPLETE (TRV315)
**************************
(Ref.No.:6000 Series)
< CAPACITOR >
C801 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C802 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C803 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C804 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C805 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C806 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C808 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C809 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C810 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C811 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C812 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C813 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C817 1-113-991-11 TANTAL. CHIP 33uF 20% 16V
C818 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C819 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C820 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C821 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C823 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C824 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C825 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C826 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(EXCEPT:TR7000/TR7000E/TR7100E)
C827 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT:TR7000/TR7000E/TR7100E)
C828 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(EXCEPT:TR7000/TR7000E/TR7100E)
C829 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT:TR7000/TR7000E/TR7100E)
C830 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT:TR7000/TR7000E/TR7100E)
C831 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
(EXCEPT:TR7000/TR7000E/TR7100E)
C832 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C833 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT:TR7000/TR7000E/TR7100E)
C834 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C836 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C837 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C838 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C840 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(EXCEPT:TR7000/TR7000E/TR7100E)
C841 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C842 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
(EXCEPT:TR7000/TR7000E/TR7100E)
C843 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C844 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C846 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C847 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C848 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C849 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
(EXCEPT:TR7000/TR7000E/TR7100E)
C850 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C851 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C852 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EXCEPT:TR7000/TR7000E/TR7100E)
C853 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT:TR7000/TR7000E/TR7100E)
C854 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
(EXCEPT:TRV315/TR7000/TR7000E/TR7100E)
C855 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C856 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C857 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3
C860 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C861 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EXCEPT:TRV/315TR7000/TR7000E/TR7100E)
C861 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(TRV315/TR7000/TR7000E/TR7100E)
C862 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT:TR7000/TR7000E/TR7100E)
C863 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT:TR7000/TR7000E/TR7100E)
C864 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C865 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EXCEPT:TR7000/TR7000E/TR7100E)
C866 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EXCEPT:TR7000/TR7000E/TR7100E)
C867 1-164-346-11 CERAMIC CHIP 1uF 16V
(TRV315/TR7000/TR7000E/TR7100E)
C868 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C869 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EXCEPT:TR7000/TR7000E/TR7100E)
C871 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C872 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C873 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT:TR7000/TR7000E/TR7100E)
C875 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
(EXCEPT:TR7000/TR7000E/TR7100E)
C876 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C877 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN801 1-580-756-21 PIN, CONNECTOR (SMD) 7P
CN931 1-774-597-41 CONNECTOR, BOARD TO BOARD 70P
(EXCEPT:TR7000/TR7000E/TR7100E)
CN931 1-793-129-21 CONNECTOR, BOARD TO BOARD 70P
(TR7000/TR7000E/TR7100E)
CN933 1-785-627-21 PIN, CONNECTOR (PC BOARD) 10P
(EXCEPT:TR7000/TR7000E/TR7100E)
CN934 1-766-342-21 CONNECTOR, FFC/FPC 12P
CN935 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN936 1-774-631-21 CONNECTOR, FFC/FPC 6P
DD-117
