6-21
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R315 1-216-833-11 METAL CHIP 10K 5% 1/16W
R316 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R317 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R318 1-414-228-11 INDUCTOR CHIP 0UH (Note)
R319 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R320 1-216-833-11 METAL CHIP 10K 5% 1/16W
R321 1-216-839-11 METAL CHIP 33K 5% 1/16W
R322 1-414-228-11 INDUCTOR CHIP 0UH (Note)
R323 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R324 1-216-839-11 METAL CHIP 33K 5% 1/16W
R325 1-216-839-11 METAL CHIP 33K 5% 1/16W
R326 1-414-228-11 INDUCTOR CHIP 0UH (Note)
R327 1-414-228-11 INDUCTOR CHIP 0UH (Note)
R331 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R332 1-216-836-11 METAL CHIP 18K 5% 1/16W
R333 1-216-839-11 METAL CHIP 33K 5% 1/16W
R334 1-216-839-11 METAL CHIP 33K 5% 1/16W
R335 1-216-864-11 METAL CHIP 0 5% 1/16W
R336 1-216-864-11 METAL CHIP 0 5% 1/16W
R338 1-216-311-00 METAL CHIP 6.8 5% 1/10W
R339 1-216-302-00 METAL CHIP 2.7 5% 1/10W
R340 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R341 1-216-864-11 METAL CHIP 0 5% 1/16W
************************************************************
EXCEPT:TR7000/TR7000E/TR7100E MODEL
A-7073-871-A PD-105(SHN) BOARD, COMPLETE
(TRV103/TRV110/TRV110E:E,HK,AUS,CN,JE/TRV110P)
***************************
A-7073-927-A PD-106(SH) BOARD, COMPLETE
(TRV203/TRV210/TRV210E/TRV315)
**************************
A-7073-942-A PD-105(SHP) BOARD, COMPLETE
(TRV110E:AEP,UK,EE,NE,RU)
***************************
A-7073-957-A PD-106(CAN) BOARD, COMPLETE
(TRV310/TRV310P)
***************************
A-7073-975-A PD-106(SHP) BOARD, COMPLETE (TRV310E)
***************************
(Ref.No.:1000 Series)
< CAPACITOR >
C5501 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5502 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5506 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5507 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C5508 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C5511 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5512 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C5513 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5514 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C5515 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C5516 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C5517 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5518 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5519 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C5520 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5602 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C5603 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
(TRV310/TRV310P)
C5603 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TRV103/TRV110/TRV110E/TRV110P/TRV203/
TRV210/TRV210E/TRV310E/TRV315)
C5604 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5605 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5607 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5608 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
C5610 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C5612 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C5616 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5618 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
(TRV103/TRV110/TRV110E/TRV110P/TRV203/
TRV210/TRV210E/TRV310E/TRV315)
C5619 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV103/TRV110/TRV110E/TRV110P/TRV203/
TRV210/TRV210E/TRV310E/TRV315)
C5620 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5621 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C5622 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C5623 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV310/TRV310P)
C5624 1-107-688-11 TANTAL. CHIP 1.5uF 20% 10V
C5625 1-107-688-11 TANTAL. CHIP 1.5uF 20% 10V
C5633 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C5701 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C5702 1-164-346-11 CERAMIC CHIP 1uF 16V
C5703 1-164-661-11 CERAMIC CHIP 0.018uF 10% 50V
C5704 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
! C5705 1-113-520-11 CERAMIC CHIP 10PF 10% 3KV
(TRV203/TRV210/TRV210E/TRV315)
! C5705 1-113-521-11 CERAMIC CHIP 12PF 10% 3KV
(TRV103/TRV110/TRV110E/TRV110P/TRV310/TRV310E/TRV310P)
C5706 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5801 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV103/TRV110/TRV110E/TRV110P)
C5900 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P/TRV315)
< CONNECTOR >
* CN5501 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5601 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN5701 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5801 1-764-532-21 CONNECTOR, FFC/FPC (ZIF) 26P
(TRV103/TRV110/TRV110E/TRV110P)
CN5802 1-785-627-21 PIN, CONNECTOR (PC BOARD) 10P
(TRV103/TRV110/TRV110E/TRV110P)
PD-105/106
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Note : Inductors are mounted to the location where R318, R322,
R326, R327 are printed.
MA-354/355/357
