Fig 4-11 Fuel system with FLV (generic and simplified)
Cyl. n
59
51
67
ENGINE
PLANT
49
50
52
60
57
PLANT
ENGINE
001 002 003 004 005
006
007
008
009
Cyl. 1
Legend
001 Pressure control valve 006 Injection valve
002 Relief valve 007 Supply unit
003 Flow limiting valve (FLV) 008 Fuel pump
004 Fuel rail 009 Pressure retaining valve
005 Rail unit
X92DF
AA00-0000-00AAA-043E-A
Operation Manual Fuel system
Winterthur Gas & Diesel Ltd.
- 100 - Issue 002 2020-08
