1.5 Data module codes (procedural data)
This manual is divided into several data modules. Each data module is identified with a unique
data module code, refer to Table 1-3 - Data module codes (procedural data). The structure of
the data module codes is as follows:
•
??##-####-##???-###?-? (structure)
•
AA00-5556-00AAA-520A-A (example).
Tab 1-3 Data module codes (procedural data)
Code Description Length/type Property Example
??
1
Alternative versions/designs of items.
Used when two or more items could be
installed in the engine as alternatives
for the same function (for example tur-
bochargers from different suppliers)
2 alphabetic
characters [A-Z]
sequential,
starts with AA
AA
##
2
Applicability related to cylinder number.
00 = applicable to all engines inde-
pendent of the number of cylinders;
## = applicable only to engines with
that specific number of cylinders.
2 numeric char-
acters [0-9]
arbitrary 00
####
2
WinGD design group number 4 numeric char-
acters [0-9]
arbitrary 5556
##
2
Used for sequential numbering for the
physical breakdown of components; 00
= complete component, 01 = first
breakdown; for illustrated parts (tools) it
is used for sequential numbering of da-
ta modules.
2 numeric char-
acters [0-9]
sequential,
starts with 00
00
???
1
Used for alternative items differing in
design but not enough to change the
variant code (for example AAA = Bear-
ing shell No.1; AAB = Bearing shell No.
2 to #)
3 alphabetic
characters [A-Z]
sequential,
starts with AAA
AAA
###
2
Shipdex information code, for example
520 = Remove procedure
3 numeric char-
acters [0-9]
Shipdex specif-
ic
520
?
1
Shipdex information code variant. Used
to differentiate different procedures de-
fined by the same information code for
the same DMC/Hardware section.
1 alphabetic
character [A-Z]
variable A
X92DF
AA00-0000-00AAA-018E-A
Operation Manual Data module codes (procedural data)
Winterthur Gas & Diesel Ltd.
- 28 - Issue 002 2020-08
