WinGD X92DF User Manual

Tab 6-5 CYLINDER BALANCING DIESEL
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 PRINT button Makes a screenshot of the current screen, refer to 6.8.31
LDU-20 page - SCREENSHOT
006 INDEX button Opens the INDEX page
007 Compr. Balancing button Changes the compression balancing function
•
Green - ON
•
Red - OFF
008 Firing Balancing button Changes the firing balancing function
•
Green - ON
•
Red - OFF
009 Firing Control button Changes the firing control function
•
Green - ON
•
Red - OFF
X92DF
AA00-9606-06AAA-043B-A
Operation Manual LDU-20 page - CYLINDER BALANCING DIESEL
Winterthur Gas & Diesel Ltd.
- 309 - Issue 002 2020-08
