Fig 5-3 Thrust bearing (generic)
001
002
003
004
005
006
007
008
007
009
006
010
011
012
013
014
015
Legend
001 Column 009 Crankshaft
002 Oil pipe 010 2-part oil baffle
003 Nozzle 011 Flywheel
004 Arbor support 012 Bedplate
005 Bedplate 013 Thrust pad (engine side)
006 Thrust pad (driving end) 014 Thrust bearing flange
007 Bearing cover 015 Column
008 Crankshaft gear wheel
X92DF
AA00-1203-00AAA-043A-A
Operation Manual Thrust bearing
Winterthur Gas & Diesel Ltd.
- 153 - Issue 002 2020-08
