Tab 6-13 FAILURE SIMULATION
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 PRINT button Makes a screenshot of the current screen, refer to section
6.8.31 LDU-20 page - SCREENSHOT
006 INDEX button Opens the INDEX page
007 Failure Test Mode button Sets to ON and OFF the failure test mode
NOTE: You only can start the test mode, if the conditions
that follow are OK:
•
Engine at standstill (green indicator light is on)
•
No shutdown signal active
•
Turning gear is engaged, thus there is a start
interlock (green indicator light is on)
008 Failure ID To Simulate Manually set the failure number related to the Modbus to AMS
signal list
NOTE: This specified failure will be sent to the RCS for a
specific test.
X92DF
AA00-9606-14AAA-043B-A
Operation Manual LDU-20 page - FAILURE SIMULATION
Winterthur Gas & Diesel Ltd.
- 327 - Issue 002 2020-08
