WinGD X92DF User Manual

Tab 6-40 iELBA Control
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 INDEX button Opens the INDEX page
006 Manual / Auto Mode Changes between automatic and manual control mode of the
iELBA
007 Free End ON/OFF In manual mode - starts and stops the iELBA on the related
engine end
008 Operator Phase Setpoint In manual mode - manually adjust the crank angle setpoint for
the related engine end in manual mode
009 Auto Phase Setpoint In manual mode - manually adjust the crank angle setpoint for
the related engine end in auto mode
X92DF
AA00-9606-42AAA-043B-A
Operation Manual LDU-20 page - iELBA Control (optional)
Winterthur Gas & Diesel Ltd.
- 383 - Issue 002 2020-08
