Fig 5-38 Pressure control valve - location (example)
003
005
006
007
008
004
001
002
Legend
001 Solenoid valve (ZV7061S) 005 Fuel return pipe
002 Pressure control valve (10-5562_E0_5) 006 Rail unit
003 Relief valve 007 Fuel rail
004 Fuel return pipe 008 Drain pipe
X92DF
AA00-5562-00AAA-043A-A
Operation Manual Pressure control valve
Winterthur Gas & Diesel Ltd.
- 217 - Issue 002 2020-08
