11.2.2 Signal codes - identification

An example of a signal code is shown in Figure 11-2.

Fig 11-2 Signal codes

PT 1012 C

001 002 003 004

00207

Legend

001 Function code 003 Running number

002 Function group 004 Applied system

Tab 11-3 Function code

Code First position Second position

A Analysis n/a

C Control Control

E n/a Element

F Flow n/a

G Gauge n/a

H Hand n/a

I n/a Indication

J Power n/a

L Level n/a

P Pressure n/a

S Speed Switch

T Temperature Transmitter

V n/a Valve

X Unclassified Unclassified

Y Vibration Relay

Z Position (binary) n/a

X92DF

AA00-0000-00AAA-030K-A

Operation Manual List of usual values and safeguard settings - general

Winterthur Gas & Diesel Ltd.

- 578 - Issue 002 2020-08

WinGD X92DF User Manual
