6.9.7 MCP page - INSTRUMENTS
Fig 6-60 MCP page - INSTRUMENTS
Tab 6-46 INSTRUMENTS
Item Function Effect
001 Indication field Shows the values of the displayed instruments
NOTE: The number of the displayed instruments is related
to the engine.
NOTE: If an instrument is unservicable, the background of
the related instrument changes to red.
X92DF
AA00-4618-02AAA-043B-A
Operation Manual MCP page - INSTRUMENTS
Winterthur Gas & Diesel Ltd.
- 398 - Issue 002 2020-08
