1/05
2-44
DocuColor 12/DCCS50
5-116 DADF Exit Sensor OFF Dynamic Jam RAP, 5-
Reissue
Status Indicator RAPs
• Exit Pinch Roll
• Document Belt
Enter dC330 005-115 Exit Sensor. Pr
ess Start. Block the DADF Exit Sensor. The display
changed from L to H.
YN
With paper at the DADF Exit Sensor, less than +1 VDC is measured at P
/J
599-19 on
the DADF Control PWB.
YN
+5 VDC is measured between P/
J5
89-1 and P/J589-3 on the DADF Exit Sen-
sor.
YN
Go to Fl
ag 3 BSD
5.5. Check the wires for an open circuit or a short circuit. If
the wires are good, replace the DADF Control PWB (PL 12.3).
Go to Flag 1 on BS
D 5.5. Check the wire for an open circuit. If the wire is good,
replace the DADF Exit Sensor (PL 12.9).
Replace the DADF Control PWB (PL 12.3).
Check
the following parts for wear slipping or damage.
• Exit Roll Drive Belt
•Exit Roll
• Exit Pinch Roll
• Document Belt
• Platen Glass
If the above items are good and free from excessive contamination, replace the DADF Exit
Sens
or (PL 12.9).
5-189 No Object Sensor Static Jam RAP
The Control Logic has detected the document Handler was raised while running a DADF job.
Initial Actions
Ensure that then document handler is fully closed.
Procedure
If the document Handler was not opened during a DADF job, go to 6-300 Platen Cover Open
RAP to troubleshoot the Platen Open Switch.
A
