Troubleshooting
WorkCentre 7425/7428/7435
User Guide
226
Clearing Main Staple Jams in the Office LX Finisher
Warning: Do not perform this procedure when the printer is copying or printing.
1. Open the finisher front cover.
2. The staple cartridge holder is located inside the finisher cabinet. Pull the staple cartridge holder
toward you until it stops.
3. Hold the staple cartridge by lever R1 and push the staple cartridge holder to the right.
4. Grip the staple cartridge holder by the orange tabs and remove it from the finisher by pulling it
firmly toward you. Check inside the finisher for any loose staples and remove them.
wc74xx-093
wc74xx-094
wc74xx-095
To Next Page
