LIGHTING SYSTEM
8-19
EAS27260
TROUBLESHOOTING
Any of the following fail to light: headlight, high beam indicator light, taillight or license plate light.
TIP
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Left side cowling
3. Air intake air duct covers
4. Meter assembly
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1. Check the each bulbs and bulb
sockets condition.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page 8-
124.
Replace the bulb(s) and bulb
socket(s).
2. Check the fuses.
(Main, headlight, ignition, turn sig-
nal light and fuel injection system)
Refer to “CHECKING THE FUSES”
on page 8-125.
Replace the fuse(s).
3. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-125.
• Clean the battery terminals.
• Recharge or replace the battery.
4. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-121.
Replace the main switch/immobilizer
nut.
5. Check the dimmer switch.
Refer to “CHECKING THE
SWITCHES” on page 8-121.
The dimmer switch is faulty. Replace
the left handlebar switch.
6. Check the pass switch.
Refer to “CHECKING THE
SWITCHES” on page 8-121.
The pass switch is faulty. Replace the
left handlebar switch.
7. Check the headlight relay.
Refer to “CHECKING THE
RELAYS” on page 8-129.
Replace the headlight relay.
