Yamaha 2009 YZF-R1 (Y) User Manual

CHASSIS SPECIFICATIONS
2-9
EAS20300
CHASSIS SPECIFICATIONS
Chassis
Frame type Diamond
Caster angle 24.0°
Trail 102.0 mm (4.02 in)
Front wheel
Wheel type Cast wheel
Rim size 17M/C × MT3.50
Rim material Aluminum
Wheel travel 120.0 mm (4.72 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Rear wheel
Wheel type Cast wheel
Rim size 17M/C × MT6.00
Rim material Aluminum
Wheel travel 120.0 mm (4.72 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Front tire
Type Tubeless
Size 120/70 ZR17M/C (58W)
Manufacturer/model MICHELIN/Pilot POWER P (14B1, 14B2)
DUNLOP/D210F (14B1, 14B3)
Wear limit (front) 1.0 mm (0.04 in) (14B3)
1.6 mm (0.06 in) (14B1, 14B2)
Rear tire
Type Tubeless
Size 190/55 ZR17M/C (75W)
Manufacturer/model MICHELIN/ Pilot POWER (14B1, 14B2)
DUNLOP/D210 (14B1, 14B3)
Wear limit (rear) 1.0 mm (0.04 in) (14B3)
1.6 mm (0.06 in) (14B1, 14B2)
Tire air pressure (measured on cold tires)
Loading condition 0–90 kg (0–198 lb)
Front 250 kPa (2.50 kgf/cm², 36 psi, 2.50 bar)
Rear 290 kPa (2.90 kgf/cm², 42 psi, 2.90 bar)
Loading condition 90–189 kg (198–417 lb)
Front 250 kPa (2.50 kgf/cm², 36 psi, 2.50 bar)
Rear 290 kPa (2.90 kgf/cm², 42 psi, 2.90 bar)
High-speed riding
Front 250 kPa (2.50 kgf/cm², 36 psi, 2.50 bar)
Rear 290 kPa (2.90 kgf/cm², 42 psi, 2.90 bar)
Front brake
Type Dual disc brake
Operation Right hand operation
Front disc brake
Disc outside diameter × thickness 310.0 × 5.0 mm (12.20 × 0.20 in)
Brake disc thickness limit 4.5 mm (0.18 in)
Brake disc deflection limit 0.10 mm (0.0039 in)

Yamaha 2009 YZF-R1 (Y) Specifications

General

Bore x Stroke	78.0 mm x 52.2 mm
Compression Ratio	12.7:1
Fuel System	Fuel injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Transmission	6-speed w/multiplate slipper clutch
Final Drive	Chain
Front Tire	120/70-ZR17
Rear Tire	190/55-ZR17
Seat Height	835 mm
Wet Weight	206 kg
Engine Type	Liquid-cooled, 4-stroke, DOHC, inline 4-cylinder
Front Suspension	43 mm inverted fork, fully adjustable
Rear Suspension	Single shock, fully adjustable
Front Brakes	Dual 310 mm discs, radial-mount 6-piston calipers
Rear Brakes	220 mm disc, single-piston caliper
Dimensions (L x W x H)	2, 070 mm x 715 mm x 1, 130 mm
Wheelbase	1415 mm
Fuel Capacity	18 L
