FUEL INJECTION SYSTEM
8-83
Fault code No. 42
Symptom A. Normal signals are not received from the speed sensor.
B. Open or short circuit of gear position sensor lead
A
Fail-safe action
Engine startup: Possible
Riding: Possible
Diagnostic monitoring
code No.
D:07 (Speed sensor)
Meter display Vehicle speed pulses: 0–999
Checking method
Make sure that the indication value increases when the rota-
tion speed of the rear wheel increases. This value is cumula-
tive and is not reset each time the wheel is prevented from
rotating.
B
Fail-safe action
Engine startup: Possible
Riding: Possible
Diagnostic monitoring
code No.
D:21 (Gear position sensor)
Meter display
Gear position switch
• ON (neutral)
•OFF (in gear)
Checking method Shift the transmission and clutch lever.
C
Fail-safe action
Engine startup: Possible
Riding: Possible
Diagnostic monitoring
code No.
D:21 (Clutch switch)
Meter display
ON (Gear is in other than neutral, operating clutch and stor-
ing sidestand.)
OFF (Gear is in other than neutral, operating clutch and
using sidestand.)
Checking method Shift the transmission, clutch lever and sidestand.
Checkpoints Inspection method
Locate the malfunction. Check in the diagnostic mode (Code No. 07).
Rotate the rear wheel and make sure that the
indication value increases. Malfunction → Go
to the “Speed sensor system malfunction”
section below.
Check in the diagnostic mode (Code No. 21).
When the gear is in neutral position: ON indi-
cation
When the gear is not in neutral position: OFF
indication
Malfunction → Go to the “Gear position sen-
sor system malfunction” section below.

Yamaha 2009 YZF-R1 (Y) Specifications

General

Bore x Stroke	78.0 mm x 52.2 mm
Compression Ratio	12.7:1
Fuel System	Fuel injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Transmission	6-speed w/multiplate slipper clutch
Final Drive	Chain
Front Tire	120/70-ZR17
Rear Tire	190/55-ZR17
Seat Height	835 mm
Wet Weight	206 kg
Engine Type	Liquid-cooled, 4-stroke, DOHC, inline 4-cylinder
Front Suspension	43 mm inverted fork, fully adjustable
Rear Suspension	Single shock, fully adjustable
Front Brakes	Dual 310 mm discs, radial-mount 6-piston calipers
Rear Brakes	220 mm disc, single-piston caliper
Dimensions (L x W x H)	2, 070 mm x 715 mm x 1, 130 mm
Wheelbase	1415 mm
Fuel Capacity	18 L
