FUEL INJECTION SYSTEM
8-69
6 Ignition coil malfunction
(Check the resistance of igni-
tion coil #2.)
Refer to “CHECKING THE
IGNITION COILS” on page 8-
132.
Ignition coil inspection
method
Start and idle the engine for
approximately 5 seconds.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
7 ECU malfunction Check in the diagnostic mode
(Code No. 31).
If not ignited, replace the
defective ECU.
Fault code No. 35
Symptom Ignition coil #3 primary lead malfunction
Fail-safe action
Engine startup: Possible (depending on the number of failed cylin-
ders)
Riding: Possible (depending on the number of failed cylinders)
Diagnostic monitor-
ing code No.
D:32
Meter display
Actuates the cylinder-#3 ignition coil five times at one-second inter-
vals.
Illuminates the engine trouble warning light.
Checking method
Check the spark five times.
• Connect an ignition checker.
Item/components and
probable cause
Check or maintenance job
Sensor inspection proce-
dure
1 Connection of ignition coil
coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
Poor connection → Connect
it securely or replace the wire
harness.
Start and idle the engine for
approximately 5 seconds.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Fault code No. 34
Symptom Ignition coil #2 primary lead malfunction
Fail-safe action
Engine startup: Possible (depending on the number of failed cylin-
ders)
Riding: Possible (depending on the number of failed cylinders)
Diagnostic monitor-
ing code No.
D:31
Meter display
Actuates the cylinder-#2 ignition coil five times at one-second inter-
vals.
Illuminates the engine trouble warning light.
Checking method
Check the spark five times.
• Connect an ignition checker.
Item/components and
probable cause
Check or maintenance job
Sensor inspection proce-
dure
To Next Page
