FUEL INJECTION SYSTEM
8-91
Fault code No. 46
Symptom Incorrect voltage is supplied to the ECU.
Fail-safe action
Engine startup: Possible
Riding: Possible
Diagnostic monitor-
ing code No.
—
Meter display —
Checking method —
Item/components and
probable cause
Check or maintenance job
Sensor inspection proce-
dure
1 Connection of ECU coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
Poor connection → Connect
it securely, or repair/replace
the wire harness.
Start and idle the engine for
approximately 5 seconds.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
2 Continuity of wire harness Open or short circuit →
Replace the wire harness.
Between the battery and
main switch
Red–Red
Between the main switch and
ignition fuse
Brown/Blue–Brown/Blue
Between the ignition fuse and
ECU
Red/White–Red/White
Start and idle the engine for
approximately 5 seconds.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
3 Battery malfunction Check the battery voltage.
Refer to “CHECKING AND
CHARGING THE BATTERY”
on page 8-125.
Battery malfunction →
Recharge or replace the bat-
tery.
Start and idle the engine for
approximately 5 seconds.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
4 Stator coil malfunction Check the stator coil output.
Refer to “CHECKING THE
STATOR COIL” on page 8-
134.
Stator coil malfunction →
Replace the stator coil.
Start and idle the engine for
approximately 5 seconds.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
5 ECU malfunction Replace the ECU.
To Next Page
