ACS550-02/U2 User’s Manual 115
Parameters
Parameters
Complete parameter list
The following table lists all parameters. Table header abbreviations are:
•S
= Parameters can be modified only when the drive is stopped.
• User = Space to enter desired parameter values.
Some values depend on the “construction” as indicated in the table by “02:” or “U2:”.
Refer to the type code on the drive, for example ACS550-02-245A-4.
Code Name Range Resolution Default User S
Group 99: START-UP DATA
9901
LANGUAGE 0…15 / 0…3 1 0 (ENGLISH)
9902 APPLIC MACRO -3…8 1 1 (ABB STANDARD) !
9904 MOTOR CTRL MODE 1=VECTOR:SPEED, 2 = VECTOR:TORQUE,
3=
SCALAR:FREQ
13 (SCALAR:FREQ) !
9905
MOTOR NOM VOLT 02: 200…600 V /
U2: 230…690 V
1 V 02: 400 V /
U2: 460 V
!
9906 MOTOR NOM CURR 0.2 · I
2hd
… 2.0 · I
2hd
0.1 A 1.0 · I
2hd
!
9907 MOTOR NOM FREQ 10.0.0…500.0 Hz 0.1 Hz 02: 50.0 Hz /
U2: 60.0 Hz
!
9908
MOTOR NOM SPEED 50…30000 rpm 1 rpm Size dependent !
9909 MOTOR NOM POWER 0.2…3.0 · P
hd
02: 0.1 kW /
U2: 0.1 hp
1.0 · P
hd
!
9910 ID RUN 0 = OFF/IDMAGN, 1 = ON 10 (OFF/IDMAGN) !
Group 01: OPERATING DATA
0101
SPEED & DIR -30000…30000 rpm 1 rpm -
0102
SPEED 0…30000 rpm 1 rpm -
0103
OUTPUT FREQ 0.0…500.0 Hz 0.1 Hz -
0104 CURRENT 0.0…2.0 · I
2hd
0.1 A -
0105
TORQUE -200.0…200.0% 0.1% -
0106
POWER -2.0…2.0 · P
hd
0.1 kW -
0107
DC BUS VOLTAGE 0…2.5 · V
dN
1V -
0109
OUTPUT VOLTAGE 0…2.0 · V
dN
1V -
0110 DRIVE TEMP 0.0…150.0 °C0.1°C-
0111 EXTERNAL REF 1 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz -
0112
EXTERNAL REF 2 0.0…100.0% (0.0…600.0% for torque) 0.1% -
0113 CTRL LOCATION 0=LOCAL, 1 = EXT1, 2 = EXT21 -
0114 RUN TIME (R) 0…9999 h 1 h 0 h
0115
KWH COUNTER (R) 0…9999 kWh 1 kWh -
0116 APPL BLK OUTPUT 0.0…100.0% (0.0…600.0% for torque) 0.1% -
0118 DI 1-3 STATUS 000…111 (0…7 decimal) 1 -
0119
DI 4-6 STATUS 000…111 (0…7 decimal) 1 -
0120 AI 1 0.0…100.0% 0.1% -
