ACS550-02/U2 User’s Manual 259
Fieldbus adapter
Diagnostics – FBA
Fault handling
The ACS550 provides fault information as follows:
• The control panel display shows a fault code and text. See chapter Diagnostics
on page 273 for a complete description.
• Parameters 0401
LAST FAULT, 0412 PREVIOUS FAULT1 and 0413 PREVIOUS FAULT2
store the most recent faults.
• For fieldbus access, the drive reports faults as a hexadecimal value, assigned
and coded according to the DRIVECOM specification. See the table below. Not all
profiles support requesting fault codes using this specification. For profiles that
support this specification, the profile documentation defines the proper fault
request process.
Drive fault code
Fieldbus fault code
(DRIVECOM
specification)
1
OVERCURRENT 2310h
2
DC OVERVOLT 3210h
3
DEV OVERTEMP 4210h
4s
HORT CIRC 2340h
5 Reserved FF6Bh
6
DC UNDERVOLT 3220h
7
AI1 LOSS 8110h
8
AI2 LOSS 8110h
9
MOT OVERTEMP 4310h
10
PANEL LOSS 5300h
11
ID RUN FAIL FF84h
12
MOTOR STALL 7121h
14
EXT FAULT 1 9000h
15
EXT FAULT 2 9001h
16
EARTH FAULT 2330h
17 Obsolete FF6Ah
18
THERM FAIL 5210h
19
OPEX LINK 7500h
20
OPEX PWR 5414h
21
CURR MEAS 2211h
22
SUPPLY PHASE 3130h
23
ENCODER ERR 7301h
24
OVERSPEED 7310h
25 Reserved FF80h
26 DRIVE ID 5400h
