ABB ACS550-02 - Technical data; Ratings

ACS550-02/U2 User’s Manual 293
Technical data
Technical data
Ratings
By type code, the table below provides ratings for the ACS550 adjustable speed AC
drive, including:
• IEC ratings
• NEMA ratings (shaded columns)
• frame size
• drive cabinet heat dissipation and air flow.
IEC ratings
NEMA ratings
Ratings (380…480 V AC supply)
Type code
ACS550-02
Normal use Heavy-duty use
Heat
dissipation
Air flow
Frame
size
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW
Wm
3
/h
-245A-4 245 132 192 110 3850 540 R7
-289A-4 289 160 224 132 4550 540 R7
-368A-4 368 200 302 160 6850 1220 R8
-486A-4 486 250 414 200 7850 1220 R8
-526A-4 526 280 477 250 7600 1220 R8
-602A-4 602 315 515 280 8100 1220 R8
-645A-4 645 355 590 315 9100 1220 R8
00467918.xls B
Ratings (380…480 V AC supply)
Type code
ACS550-U2
UL Type 1
(NEMA 1)
Normal use Heavy-duty use
Heat
dissipation
Air flow
Frame
size
I
2N
A
P
N
hp
I
2hd
A
P
hd
hp
BTU/hr ft
3
/min
-196A-4
1
196 150 162 125 10416 318 R7
-245A-4
1
245 200 192 150 13148 318 R7
-316A-4 316
250 240 200 23394 718 R8
-368A-4 368
300 302 250 23394 718 R8
-414A-4 414
350 368 300 26809 718 R8
-486A-4 486
400 414 350 26809 718 R8
-526A-4 526
450 477 400 25955 718 R8
-602A-4 602
500 515 450 27663 718 R8
-645A-4 645
550 590 500 31078 718 R8
00467918.xls B
1. ACS550-U2-196A-4 and ACS550-U2-245A-4 will be discontinued. Consult US factory.
