304 ACS550-02/U2 User’s Manual
Technical data
Materials
Applicable standards
Drive compliance with the following standards is identified by the standard “marks”
on the type code label. The compliance with the European Low Voltage Directive is
verified according to standards EN 50178 and EN 60204-1.
Materials specifications
Drive enclosure
• PC/ABS 2.5 mm, color NCS 1502-Y (RAL 90021/PMS 420 C)
• Hot-dip zinc coated steel sheet 1.5…2 mm, thickness of coating 100
micrometers
• Extruded aluminum AlSi
Package
Plywood box (drives and option modules), expanded polystyrene. Plastic
covering of the package PE-LD, bands PP or steel.
Disposal
The drive contains raw materials that should be recycled to preserve energy
and natural resources. The package materials are environmentally compatible
and recyclable. All metal parts can be recycled. The plastic parts can either be
recycled or burned under controlled circumstances, according to local
regulations. Most recyclable parts are marked with recycling marks.
If recycling is not feasible, all parts excluding electrolytic capacitors and printed
circuit boards can be landfilled. Plywood box has to be burned in high
temperature. The DC capacitors contain electrolyte and the printed circuit
boards contain lead, both of which are classified as hazardous waste within the
EU. They must be removed and handled according to local regulations.
For further information on environmental aspects and more detailed recycling
instructions, please contact your local ABB representative.
Mark Applicable standards
EN 50178 (1997) Electronic equipment for use in power installations
IEC/EN 60204-1 (2005) Safety of machinery. Electrical equipment of machines.
Part 1: General requirements. Provisions for compliance: The
final assembler of the machine is responsible for installing:
• an emergency-stop device
• a supply disconnecting device.
IEC/EN 60529 (2004) Degrees of protection provided by enclosures (IP code)
IEC 60664-1 (2002)
Insulation coordination for equipment within low-voltage
systems. Part 1: Principles, requirements and tests
IEC/EN 61800-5-1 (2003)
Adjustable speed electrical power drive systems.
Part 5-1: Safety requirements. Electrical, thermal and energy
IEC/EN 61800-3 (2004) Adjustable speed electrical power drive systems.
Part 3: EMC requirements and specific test methods
IEC/EN 61800-3 (2004) Adjustable speed electrical power drive systems.
Part 3: EMC requirements and specific test methods
UL 508C UL Standard for Safety, Power Conversion Equipment, third
edition
