ACS550-02/U2 User’s Manual 297
Technical data
Cable types
IEC
The table below gives copper and aluminium cable types for different load currents.
Cable sizing is based on max. 9 cables laid on a cable ladder side by side, ambient
temperature 30 °C, PVC insulation, surface temperature 70 °C (EN 60204-1 and
IEC 60364-5-52/2001). For other conditions, size the cables according to local
safety regulations, appropriate input voltage and the load current of the drive.
In any case, the cable must be between the minimum limit defined in this table and
the maximum limit defined by the terminal size (see Cable entries on page 299).
Copper cables with
concentric copper shield
Aluminium cables with
concentric copper shield
Max. load current
A
Cable type
mm
2
Max. load current
A
Cable type
mm
2
56 3×16 69 3×35
71 3×25 83 3×50
88 3×35 107 3×70
107 3×50 130 3×95
137 3×70 151 3×120
167 3×95 174 3×150
193 3×120 199 3×185
223 3×150 235 3×240
255 3×185 214 2 × (3×70)
301 3×240 260 2 × (3×95)
274 2 × (3×70) 302 2 × (3×120)
334 2 × (3×95) 348 2 × (3×150)
386 2 × (3×120) 398 2 × (3×185)
446 2 × (3×150) 470 2 × (3×240)
510 2 × (3×185) 522 3 × (3×150)
602 2 × (3×240) 597 3 × (3×185)
579 3 × (3×120) 705 3 × (3×240)
669 3 × (3×150)
765 3 × (3×185)
903 3 × (3×240)
3BFA01051905 C
