262 ACS550-02/U2 User’s Manual
Fieldbus adapter
ABB Drives profile technical data
Overview
The ABB Drives profile provides a standard profile that can be used on multiple
protocols, including protocols available on the FBA module. This section describes
the ABB Drives profile implemented for FBA modules.
Control Word
As described earlier in section Control interface on page 252, the
CONTROL WORD is
the principal means for controlling the drive from a fieldbus system.
The following table and the state diagram later in this sub-section describe the
CONTROL WORD content for the ABB Drives profile.
ABB Drives profile (FBA) CONTROL WORD
Bit Name Value Commanded state Comments
0OFF1
CONTROL
1
READY TO OPERATE Enter READY TO OPERATE
0 EMERGENCY OFF Drive ramps to stop according to currently
active deceleration ramp (2203 or 2205)
Normal command sequence:
•Enter OFF1 ACTIVE
• Proceed to READY TO SWITCH ON,
unless other interlocks (
OFF2, OFF3) are
active.
1OFF2
CONTROL
1
OPERATING Continue operation (OFF2 inactive)
0
EMERGENCY OFF Drive coasts to stop.
Normal command sequence:
•Enter
OFF2 ACTIVE
• Proceed to SWITCHON INHIBITED
2OFF3
CONTROL
1 OPERATING Continue operation (OFF3 inactive)
0
EMERGENCY STOP Drive stops within in time specified by
parameter 2208.
Normal command sequence:
•Enter
OFF3 ACTIVE
• Proceed to SWITCH ON INHIBITED
WARNING! Be sure motor and
driven equipment can be stopped
using this mode.
3INHIBIT
OPERATION
1
OPERATION
ENABLED
Enter OPERATION ENABLED (Note the Run
enable signal must be active. See 1601. If
1601 is set to
COMM, this bit also actives
the Run Enable signal.)
0
OPERATION
INHIBITED
Inhibit operation. Enter OPERATION
INHIBITED
4 RAMP_OUT_
ZERO
1 NORMAL OPERATION Enter RAMP FUNCTION GENERATOR:
ACCELERATION ENABLED
0 RFG OUT ZERO Force ramp function generator output to
Zero. Drive ramps to stop (current and DC
voltage limits in force).
