ACS550-02/U2 User’s Manual 71
Control panels
Control panels
About control panels
Use a control panel to control the drive, read status data and adjust parameters. The
drive works with either of two different control panel types:
• Basic Control Panel – This panel (described in section Basic Control Panel on
page 92) provides basic tools for manual entry of parameter values.
• Assistant Control Panel – This panel (described below) includes pre-programmed
assistants to automate the most common parameter setups. The panel provides
language support. It is available with different language sets.
Compatibility
The manual is compatible with the following panel versions:
• Basic Control Panel: ACS-CP-C Rev. K
• Assistant Control Panel (Area 1): ACS-CP-A Rev. Y
• Assistant Control Panel (Area 2): ACS-CP-L Rev. E
• Assistant Control Panel (Asia): ACS-CP-D Rev. M
See page 75 for how to find out the version of your Assistant Control Panel. See
parameter 9901
LANGUAGE to see the languages supported by the different Assistant
Control Panels.
