ACS550-02/U2 User’s Manual 183
Parameters
Group 36: TIMED FUNCTIONS
This group defines the timed functions. The timed functions include:
• four daily start and stop times
• four weekly start, stop and boost times
• four timers for collecting selected periods together.
A timer can be connected to multiple time periods and a time period can be in
multiple timers.
A parameter can be connected to only one timer.
Time Period 1
3602 START TIME 1
3603
STOP TIME 1
3604 START DAY 1
3605
STOP DAY 1
Time Period 4
3614 START TIME 4
3615 STOP TIME 4
3616
START DAY 4
3617
STOP DAY 4
Time Period 3
3610 START TIME 3
3611 STOP TIME 3
3612
START DAY 3
3613
STOP DAY 3
Time Period 2
3606 START TIME 2
3607
STOP TIME 2
3608 START DAY 2
3609
STOP DAY 2
Booster
3622
BOOSTER SEL
3623 BOOSTER TIME
Timer 1
3626 TIMED FUNC 1 SRC
Timer 2
3627 TIMED FUNC 2 SRC
Timer 3
3628 TIMED FUNC 3 SRC
Timer 4
3629 TIMED FUNC 4 SRC
Timer 2
3627
TIMED FUNC 2 SRC
1001 EXT1 COMMANDS
1002 EXT2 COMMANDS
1102 EXT1/EXT2 SEL
1201 CONST SPEED SEL
1401 RELAY OUTPUT 1…1403 RELAY OUTPUT 3
4027
PID 1 PARAM SET
Timer 1
3626
TIMED FUNC 1 SRC
8126 TIMED AUTOCHNG
1410 RELAY OUTPUT 4…1412 RELAY OUTPUT 6
