74 ACS550-02/U2 User’s Manual
Control panels
Initially, the panel is in the Output mode, where you can
start, stop, change the direction, switch between local and
remote control, modify the reference value and monitor up
to three actual values. To do other tasks, go first to the
Main menu and select the appropriate mode on the menu.
The status line (see section Status line on page 73) shows
the name of the current menu, mode, item or state.
How to do common tasks
The table below lists common tasks, the mode in which you can perform them and
the page number where the steps to do the task are described in detail.
Task Mode Page
How to get help Any 75
How to find out the panel version At power up 75
How to adjust the display contrast Output 78
How to switch between local and remote control Any 76
How to start and stop the drive Any 76
How to change the direction of the motor rotation Output 77
How to set the speed, frequency or torque reference Output 78
How to change the value of a parameter Parameters 79
How to select the monitored signals Parameters 80
How to do guided tasks (specification of related parameter sets)
with assistants
Assistants 81
How to view and edit changed parameters Changed Parameters 84
How to view faults Fault Logger 85
How to reset faults and alarms Output, Fault 279
How to show/hide the clock, change date and time formats, set the
clock and enable/disable automatic clock transitions according to
the daylight saving changes
Time and Date 86
How to copy parameters from the drive to the control panel Parameter Backup 89
How to restore parameters from the control panel to the drive Parameter Backup 89
How to view backup information Parameter Backup 90
How to edit and change parameter settings related to I/O terminals I/O Settings 91
PARAMETERS
ASSISTANTS
CHANGED PAR
EXIT ENTER
00:00
MAIN MENU 1
LOC
5 A
1 Hz
7 %10.
0.
49.
49.1Hz
LOC
DIR
MENU00:00
