Name Values (Range) Unit Step Default Description
kIN 0.00 - 2.00 - 0.01 1.00 IDMT time multiplier for non-directional
residual overcurrent
OpUN> Off
On
- - Off Operation of non-directional residual
overvoltage
UN> 1.00 - 300.00 %UB 0.01 20.00 Set level for non-dir residual voltage, % of
UBase
tUN 0.000 - 60.000 s 0.001 0.100 Time delay for non-directional residual
overvoltage
INRel> 0.25 - 200.00 %IB 0.01 1.00 Residual release current for all directional
modes, in % of IBase
UNRel> 1.00 - 300.00 %UB 0.01 3.00 Residual release volt for all dir modes, %
of UBase
Table 99: SDEPSDE Non group settings (basic)
Name Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
8.3.6 Monitored data
Table 100: SDEPSDE Monitored data
Name
Type Values (Range) Unit Description
INCOSPHI REAL - A Mag of residual current
along polarizing qty
3I0cos(Fi-RCA)
IN
REAL - A Measured magnitude of
the residual current 3I0
UN REAL - kV Measured magnitude of
the residual voltage 3U0
SN REAL - MVA Measured magnitude of
residual power
3I03U0cos(Fi-RCA)
ANG FI-RCA
REAL - deg Angle between 3U0 and
3I0 minus RCA (Fi-RCA)
8.3.7 Operation principle
8.3.7.1 Function inputs
The function is using phasors of the residual current and voltage. Group signals I3P
and U3P containing phasors of residual current and voltage is taken from pre-
processor blocks.
The sensitive directional earth fault protection has the following sub-functions
included:
Section 8 1MRK 502 048-UEN A
Current protection
206
Technical manual
