8.4.5 Settings
Table 104: TRPTTR Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
IRef 10.0 - 1000.0 %IB 1.0 100.0 Reference current in % of IBase
IBase1 30.0 - 250.0 %IB 1.0 100.0 Base current IBase1 without cooling input
in % of IBase
IBase2 30.0 - 250.0 %IB 1.0 100.0 Base current IBase2 with cooling input in
% of IBase
Tau1 1.0 - 500.0 Min 1.0 60.0 Time constant without cooling input
Tau2 1.0 - 500.0 Min 1.0 60.0 Time constant with cooling input
IHighTau1 30.0 - 250.0 %IB1 1.0 100.0 Current setting for rescaling TC1 by TC1-
IHIGH
Tau1High 5 - 2000 %tC1 1 100 Multiplier to TC1 when current is >IHIGH-
TC1
ILowTau1 30.0 - 250.0 %IB1 1.0 100.0 Current setting for rescaling TC1 by TC1-
ILOW
Tau1Low 5 - 2000 %tC1 1 100 Multiplier to TC1 when current is <ILOW-
TC1
IHighTau2 30.0 - 250.0 %IB2 1.0 100.0 Current setting for rescaling TC2 by TC2-
IHIGH
Tau2High 5 - 2000 %tC2 1 100 Multiplier to TC2 when current is >TC2-
IHIGH
ILowTau2 30.0 - 250.0 %IB2 1.0 100.0 Current setting for rescaling TC2 by TC2-
ILOW
Tau2Low 5 - 2000 %tC2 1 100 Multiplier to TC2 when current is <ILOW-
TC2
ITrip 50.0 - 250.0 %IBx 1.0 110.0 Steady state operate current level
Alarm1 50.0 - 99.0 %Itr 1.0 80.0 First alarm level
Alarm2 50.0 - 99.0 %Itr 1.0 90.0 Second alarm level
ResLo 10.0 - 95.0 %Itr 1.0 60.0 Lockout reset level
Warning 1.0 - 500.0 Min 0.1 30.0 Time setting, below which warning would
be set
Table 105: TRPTTR Non group settings (basic)
Name
Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
Section 8 1MRK 502 048-UEN A
Current protection
216
Technical manual
