12.7.4 Signals
Table 272: SPC8GGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 2 Operator place selection
Table 273: SPC8GGIO Output signals
Name Type Description
OUT1 BOOLEAN Output 1
OUT2 BOOLEAN Output 2
OUT3 BOOLEAN Output 3
OUT4 BOOLEAN Output 4
OUT5 BOOLEAN Output 5
OUT6 BOOLEAN Output 6
OUT7 BOOLEAN Output 7
OUT8 BOOLEAN Output 8
12.7.5 Settings
Table 274: SPC8GGIO Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
Latched1 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for output
1
tPulse1 0.01 - 6000.00 s 0.01 0.10 Output 1 Pulse Time
Latched2 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for output
2
tPulse2 0.01 - 6000.00 s 0.01 0.10 Output 2 Pulse Time
Latched3 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for output
3
tPulse3 0.01 - 6000.00 s 0.01 0.10 Output 3 Pulse Time
Latched4 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for output
4
tPulse4 0.01 - 6000.00 s 0.01 0.10 Output 4 Pulse Time
Latched5 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for output
5
tPulse5 0.01 - 6000.00 s 0.01 0.10 Output 5 Pulse Time
Latched6 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for output
6
tPulse6 0.01 - 6000.00 s 0.01 0.10 Output 6 Pulse Time
Table continues on next page
Section 12 1MRK 502 048-UEN A
Control
422
