The Denial of Service functions DOSLAN1 and DOSFRNT are included to limit the
inbound network traffic. The communication can thus never compromise the primary
functionality of the IED.
The event system has a rate limiter to reduce CPU load. The event channel has a quota
of 10 events/second after the initial 30 events/second. If the quota is exceeded the
event channel transmission is blocked until the event changes is below the quota, no
event is lost.
All communication connectors, except for the front port connector, are placed on
integrated communication modules. The IED is connected to Ethernet-based
communication systems via the fibre-optic multimode LC connector(s) (100BASE-
FX).
The IED supports SNTP and IRIG-B time synchronization methods with a time-
stamping accuracy of ±1 ms.
• Ethernet based: SNTP and DNP3
• With time synchronization wiring: IRIG-B
The IED supports IEC 60870-5-103 time synchronization methods with a time
stamping accuracy of ±5 ms.
16.2.3 Communication interfaces and protocols
Table 460: Supported station communication interfaces and protocols
Protocol
Ethernet Serial
100BASE-FX LC
Glass fibre (ST
connector)
EIA-485
IEC 61850–8–1 ● - -
DNP3 ● ● ●
IEC 60870-5-103 - ● ●
● = Supported
16.2.4 Settings
Table 461: IEC61850-8-1 Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
PortSelGOOSE Front
LAN1
- - LAN1 Port selection for GOOSE communication
PortSelMMS Front
LAN1
Front+LAN1
-
- LAN1 Port selection for MMS communication
Section 16 1MRK 502 048-UEN A
Station communication
596
Technical manual
