IPOS1 IPOS2 Name of displayed string Default string value
0 0 PosUndefined P00
1 0 Position1 P01
0 1 Position2 P10
1 1 PosBadState P11
12.6 IEC 61850 generic communication I/O functions
DPGGIO
12.6.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
IEC 61850 generic communication I/O
functions
DPGGIO - -
12.6.2 Functionality
The IEC 61850 generic communication I/O functions DPGGIO function block is used
to send double indications to other systems or equipment in the substation using
IEC61850. It is especially used in the interlocking and reservation station-wide logics.
12.6.3 Function block
DPGGIO
OPEN
CLOSE
VALID
POSITION
IEC09000075_1_en.vsd
IEC09000075 V1 EN
Figure 205: DPGGIO function block
12.6.4 Signals
Table 270: DPGGIO Input signals
Name
Type Default Description
OPEN BOOLEAN 0 Open indication
CLOSE BOOLEAN 0 Close indication
VALID BOOLEAN 0 Valid indication
Table 271: DPGGIO Output signals
Name
Type Description
POSITION INTEGER Double point indication
Section 12 1MRK 502 048-UEN A
Control
420
Technical manual
