Table 211: SESRSYN Non group settings (basic)
Name Values (Range) Unit Step Default Description
GblBaseSelBus 1 - 6 - 1 1 Selection of one of the Global Base Value
groups, Bus
GblBaseSelLine 1 - 6 - 1 1 Selection of one of the Global Base Value
groups, Line
SelPhaseBus1 Phase L1
Phase L2
Phase L3
Phase L1L2
Phase L2L3
Phase L3L1
Positive sequence
-
- Phase L1 Select phase for busbar1
SelPhaseBus2 Phase L1
Phase L2
Phase L3
Phase L1L2
Phase L2L3
Phase L3L1
Positive sequence
-
- Phase L1 Select phase for busbar2
SelPhaseLine1 Phase L1
Phase L2
Phase L3
Phase L1L2
Phase L2L3
Phase L3L1
Positive sequence
-
- Phase L1 Select phase for line1
SelPhaseLine2 Phase L1
Phase L2
Phase L3
Phase L1L2
Phase L2L3
Phase L3L1
Positive sequence
-
- Phase L1 Select phase for line2
12.1.6 Monitored data
Table 212: SESRSYN Monitored data
Name
Type Values (Range) Unit Description
UDIFFME REAL - - Calculated difference of
voltage in p.u of set
voltage base value
FRDIFFME
REAL - Hz Calculated difference of
frequency
PHDIFFME REAL - deg Calculated difference of
phase angle
UBUS REAL - kV Bus voltage
ULINE REAL - kV Line voltage
Section 12 1MRK 502 048-UEN A
Control
326
