12.9.4 Settings
Table 280: I103CMD Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
12.10 IED commands for IEC 60870-5-103 I103IEDCMD
12.10.1 Functionality
I103IEDCMD is a command block in control direction with defined IED functions.
All outputs are pulsed and they are NOT stored. Pulse length is fixed to 400ms.
12.10.2 Function block
IEC10000283-1-en.vsd
I103IEDCMD
BLOCK 19-LEDRS
23-GRP1
24-GRP2
25-GRP3
26-GRP4
IEC10000283 V1 EN
Figure 209: I103IEDCMD function block
12.10.3 Signals
Table 281: I103IEDCMD Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of commands
Table 282: I103IEDCMD Output signals
Name
Type Description
19-LEDRS BOOLEAN Information number 19, reset LEDs
23-GRP1 BOOLEAN Information number 23, activate setting group 1
24-GRP2 BOOLEAN Information number 24, activate setting group 2
25-GRP3 BOOLEAN Information number 25, activate setting group 3
26-GRP4 BOOLEAN Information number 26, activate setting group 4
1MRK 502 048-UEN A Section 12
Control
427
Technical manual
