17.3.3 Parameter setting groups ACTVGRP
17.3.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Parameter setting groups ACTVGRP - -
17.3.3.2 Function block
ACTVGRP
ACTGRP1
ACTGRP2
ACTGRP3
ACTGRP4
GRP1
GRP2
GRP3
GRP4
SETCHGD
IEC09000064_en_1.vsd
IEC09000064 V1 EN
Figure 302: ACTVGRP function block
17.3.3.3 Signals
Table 500: ACTVGRP Input signals
Name
Type Default Description
ACTGRP1 BOOLEAN 0 Selects setting group 1 as active
ACTGRP2 BOOLEAN 0 Selects setting group 2 as active
ACTGRP3 BOOLEAN 0 Selects setting group 3 as active
ACTGRP4 BOOLEAN 0 Selects setting group 4 as active
Table 501: ACTVGRP Output signals
Name
Type Description
GRP1 BOOLEAN Setting group 1 is active
GRP2 BOOLEAN Setting group 2 is active
GRP3 BOOLEAN Setting group 3 is active
GRP4 BOOLEAN Setting group 4 is active
SETCHGD BOOLEAN Pulse when setting changed
17.3.3.4 Settings
The function does not have any settings available in Local HMI or Protection and
Control IED Manager (PCM600).
Section 17 1MRK 502 048-UEN A
Basic IED functions
630
Technical manual
