Table 311: XOR Output signals
Name Type Description
OUT BOOLEAN Output signal
NOUT BOOLEAN Inverted output signal
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
13.3.1.7 Loop delay function block LOOPDELAY
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Logic loop delay function block LOOPDELAY - -
The Logic loop delay function block (LOOPDELAY) function is used to delay the
output signal one execution cycle.
Function block
LOOPDELAY
INPUT OUT
IEC09000296-1-en.vsd
IEC09000296 V1 EN
Figure 222: LOOPDELAY function block
Signals
Table 312: LOOPDELAY Input signals
Name
Type Default Description
INPUT BOOLEAN 0 Input signal
Table 313: LOOPDELAY Output signals
Name
Type Description
OUT BOOLEAN Output signal, signal is delayed one execution
cycle
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
Section 13 1MRK 502 048-UEN A
Logic
446
Technical manual
