Name Type Description
HMICTR6 INTEGER Bitmask output 6 to local remote LHMI input
HMICTR7 INTEGER Bitmask output 7 to local remote LHMI input
HMICTR8 INTEGER Bitmask output 8 to local remote LHMI input
HMICTR9 INTEGER Bitmask output 9 to local remote LHMI input
HMICTR10 INTEGER Bitmask output 10 to local remote LHMI input
HMICTR11 INTEGER Bitmask output 11 to local remote LHMI input
HMICTR12 INTEGER Bitmask output 12 to local remote LHMI input
12.2.7.5 Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
12.2.8 Select release SELGGIO
12.2.8.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Select release SELGGIO - -
12.2.8.2 Function block
SELGGIO
SELECT1
SELECT2
SELECT3
SELECT4
SELECT5
SELECT6
SELECT7
SELECT8
SELECT9
SELECT10
SELECT11
SELECT12
SELECT13
SELECT14
SELECT15
SELECT16
RESERVED
IEC09000084_1_en.vsd
IEC09000084 V1 EN
Figure 173: SELGGIO function block
12.2.8.3 Signals
Table 231: SELGGIO Input signals
Name
Type Default Description
SELECT1 BOOLEAN 0 Select signal of control 1
SELECT2 BOOLEAN 0 Select signal of control 2
SELECT3 BOOLEAN 0 Select signal of control 3
Table continues on next page
1MRK 502 048-UEN A Section 12
Control
347
Technical manual
