ABB REG650 User Manual

Function block
INVERTER
INPUT OUT
IEC09000287-1-en.vsd
IEC09000287 V1 EN
Figure 218: INVERTER function block
Signals
Table 302: INVERTER Input signals
Name Type Default Description
INPUT BOOLEAN 0 Input signal
Table 303: INVERTER Output signals
Name Type Description
OUT BOOLEAN Output signal
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
13.3.1.4 PULSETIMER function block
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
PULSETIMER function block PULSETIMER - -
Functionality
The pulse function can be used, for example for pulse extensions or limiting of
operation of outputs. The PULSETIMER has a settable length.
Function block
PULSETIMER
INPUT OUT
IEC09000291-1-en.vsd
IEC09000291 V1 EN
Figure 219: PULSETIMER function block
1MRK 502 048-UEN A Section 13
Logic
443
Technical manual
