Table 395: B1RBDR Input signals
Name Type Default Description
INPUT1 BOOLEAN 0 Binary channel 1
INPUT2 BOOLEAN 0 Binary channel 2
INPUT3 BOOLEAN 0 Binary channel 3
INPUT4 BOOLEAN 0 Binary channel 4
INPUT5 BOOLEAN 0 Binary channel 5
INPUT6 BOOLEAN 0 Binary channel 6
INPUT7 BOOLEAN 0 Binary channel 7
INPUT8 BOOLEAN 0 Binary channel 8
INPUT9 BOOLEAN 0 Binary channel 9
INPUT10 BOOLEAN 0 Binary channel 10
INPUT11 BOOLEAN 0 Binary channel 11
INPUT12 BOOLEAN 0 Binary channel 12
INPUT13 BOOLEAN 0 Binary channel 13
INPUT14 BOOLEAN 0 Binary channel 14
INPUT15 BOOLEAN 0 Binary channel 15
INPUT16 BOOLEAN 0 Binary channel 16
14.4.5.4 Settings
B1RBDR - B6RBDR Settings
Setting tables for B1RBDR - B6RBDR are all similar except for binary channel and
description numbers.
• B1RBDR, channel1 - channel16
• B2RBDR, channel17 - channel32
• B3RBDR, channel33 - channel48
• B4RBDR, channel49 - channel64
• B5RBDR, channel65 - channel80
• B6RBDR, channel81 - channel96
Table 396: B1RBDR Non group settings (basic)
Name
Values (Range) Unit Step Default Description
TrigDR01 Off
On
- - Off Trigger operation On/Off
SetLED01 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 1
TrigDR02 Off
On
- - Off Trigger operation On/Off
Table continues on next page
1MRK 502 048-UEN A Section 14
Monitoring
523
Technical manual
