ABB REG650 User Manual

14.11.4 Signals
Table 405: SP16GGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
IN1 BOOLEAN 0 Input 1 status
IN2 BOOLEAN 0 Input 2 status
IN3 BOOLEAN 0 Input 3 status
IN4 BOOLEAN 0 Input 4 status
IN5 BOOLEAN 0 Input 5 status
IN6 BOOLEAN 0 Input 6 status
IN7 BOOLEAN 0 Input 7 status
IN8 BOOLEAN 0 Input 8 status
IN9 BOOLEAN 0 Input 9 status
IN10 BOOLEAN 0 Input 10 status
IN11 BOOLEAN 0 Input 11 status
IN12 BOOLEAN 0 Input 12 status
IN13 BOOLEAN 0 Input 13 status
IN14 BOOLEAN 0 Input 14 status
IN15 BOOLEAN 0 Input 15 status
IN16 BOOLEAN 0 Input 16 status
14.11.5 Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
14.11.6 MonitoredData
Table 406: SP16GGIO Monitored data
Name
Type Values (Range) Unit Description
OUT1 GROUP
SIGNAL
- - Output 1 status
OUT2 GROUP
SIGNAL
- - Output 2 status
OUT3 GROUP
SIGNAL
- - Output 3 status
OUT4 GROUP
SIGNAL
- - Output 4 status
OUT5 GROUP
SIGNAL
- - Output 5 status
OUT6 GROUP
SIGNAL
- - Output 6 status
Table continues on next page
Section 14 1MRK 502 048-UEN A
Monitoring
546
Technical manual
