ABB REG650 User Manual

Name Values (Range) Unit Step Default Description
AccCurrAlmLvl 0.00 - 20000.00 - 0.01 2500.00 Setting of alarm level for accumulated
currents power
AccCurrLO 0.00 - 20000.00 - 0.01 2500.00 Lockout limit setting for accumulated
currents power
DirCoef -3.00 - -0.50 - 0.01 -1.50 Directional coefficient for CB life
calculation
LifeAlmLevel 0 - 99999 - 1 5000 Alarm level for CB remaining life
OpNumRatCurr 1 - 99999 - 1 10000 Number of operations possible at rated
current
OpNumFaultCurr 1 - 10000 - 1 1000 Number of operations possible at rated
fault current
OpNumAlm 0 - 9999 - 1 200 Alarm limit for number of operations
OpNumLO 0 - 9999 - 1 300 Lockout limit for number of operations
tOpenAlm 0 - 200 ms 1 40 Alarm level setting for open travel time
tCloseAlm 0 - 200 ms 1 40 Alarm level setting for close travel time
OpenTimeCorr 0 - 100 ms 1 10 Correction factor for open travel time
CloseTimeCorr 0 - 100 ms 1 10 Correction factor for CB close travel time
DifTimeCorr -10 - 10 ms 1 5 Correction factor for time difference in
auxiliary and main contacts open time
tSprngChrgAlm 0.00 - 60.00 s 0.01 1.00 Setting of alarm for spring charging time
tPressAlm 0.00 - 60.00 s 0.01 0.10 Time delay for gas pressure alarm
TPressLO 0.00 - 60.00 s 0.01 0.10 Time delay for gas pressure lockout
AccEnerInitVal 0.00 - 9999.99 - 0.01 0.00 Accumulation energy initial value
CountInitVal 0 - 9999 - 1 0 Operation numbers counter initialization
value
CBRemLife 0 - 9999 - 1 5000 Initial value for the CB remaining life
estimates
InactDayAlm 0 - 9999 Day 1 2000 Alarm limit value of the inactive days
counter
InactDayInit 0 - 9999 Day 1 0 Initial value of the inactive days counter
InactHourAlm 0 - 23 Hour 1 0 Alarm time of the inactive days counter in
hours
14.17.6 Monitored data
Table 431: SSCBR Monitored data
Name
Type Values (Range) Unit Description
CBOTRVT REAL - ms Travel time of the CB
during opening operation
CBCLTRVT REAL - ms Travel time of the CB
during closing operation
SPRCHRT REAL - s The charging time of the
CB spring
NO_OPR INTEGER - - Number of CB operation
cycle
Table continues on next page
Section 14 1MRK 502 048-UEN A
Monitoring
562
Technical manual
