ABB REG650 User Manual

Name Values (Range) Unit Step Default Description
UAmpComp100 -10.000 - 10.000 % 0.001 0.000 Amplitude factor to calibrate voltage at
100% of Ur
IAmpComp5 -10.000 - 10.000 % 0.001 0.000 Amplitude factor to calibrate current at 5%
of Ir
IAmpComp30 -10.000 - 10.000 % 0.001 0.000 Amplitude factor to calibrate current at
30% of Ir
IAmpComp100 -10.000 - 10.000 % 0.001 0.000 Amplitude factor to calibrate current at
100% of Ir
IAngComp5 -10.000 - 10.000 Deg 0.001 0.000 Angle calibration for current at 5% of Ir
IAngComp30 -10.000 - 10.000 Deg 0.001 0.000 Angle calibration for current at 30% of Ir
IAngComp100 -10.000 - 10.000 Deg 0.001 0.000 Angle calibration for current at 100% of Ir
14.1.2.5 Monitored data
Table 349: CVMMXN Monitored data
Name Type Values (Range) Unit Description
S REAL - MVA Apparent power
magnitude of deadband
value
P
REAL - MW Active power magnitude
of deadband value
Q REAL - MVAr Reactive power
magnitude of deadband
value
PF
REAL - - Power factor magnitude
of deadband value
U REAL - kV Calculated voltage
magnitude of deadband
value
I
REAL - A Calculated current
magnitude of deadband
value
F
REAL - Hz System frequency
magnitude of deadband
value
14.1.3 Phase current measurement CMMXU
14.1.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Phase current measurement CMMXU
I
SYMBOL-SS V1 EN
-
1MRK 502 048-UEN A Section 14
Monitoring
477
Technical manual
