13.5.5 Settings
The function does not have any parameters available in local HMI or Protection and
Control IED Manager (PCM600)
13.5.6 Monitored data
Table 332: B16I Monitored data
Name Type Values (Range) Unit Description
OUT INTEGER - - Output value
13.5.7 Operation principle
The Boolean 16 to integer conversion function (B16I) will transfer a combination of
up to 16 binary inputs INx, where 1≤x≤16, to an integer. Each INx represents a value
according to the table below from 0 to 32768. This follows the general formula: INx
= 2
x-1
where 1≤x≤16. The sum of all the values on the activated INx will be available
on the output OUT as a sum of the integer values of all the inputs INx that are activated.
OUT is an integer. When all INx (where 1≤x≤16) are activated, that is = Boolean 1, it
corresponds to that integer 65535 is available on the output OUT. The B16I function
is designed for receiving up to 16 booleans input locally. If the BLOCK input is
activated, it will freeze the output at the last value.
Values of each of the different OUTx from function block B16I for 1≤x≤16.
The sum of the value on each INx corresponds to the integer presented on the output
OUT on the function block B16I
Name of input
Type Default Description Value when
activated
Value when
deactivated
IN1 BOOLEAN 0 Input 1 1 0
IN2 BOOLEAN 0 Input 2 2 0
IN3 BOOLEAN 0 Input 3 4 0
IN4 BOOLEAN 0 Input 4 8 0
IN5 BOOLEAN 0 Input 5 16 0
IN6 BOOLEAN 0 Input 6 32 0
IN7 BOOLEAN 0 Input 7 64 0
IN8 BOOLEAN 0 Input 8 128 0
IN9 BOOLEAN 0 Input 9 256 0
IN10 BOOLEAN 0 Input 10 512 0
IN11 BOOLEAN 0 Input 11 1024 0
IN12 BOOLEAN 0 Input 12 2048 0
IN13 BOOLEAN 0 Input 13 4096 0
Table continues on next page
Section 13 1MRK 502 048-UEN A
Logic
456
Technical manual
