3.4 Settings
Dependent on ordered IED type.
Table 1: AISVBAS Non group settings (basic)
Name Values (Range) Unit Step Default Description
PhaseAngleRef TRM - Channel 1
TRM - Channel 2
TRM - Channel 3
TRM - Channel 4
TRM - Channel 5
TRM - Channel 6
TRM - Channel 7
TRM - Channel 8
TRM - Channel 9
TRM - Channel 10
AIM - Channel 1
AIM - Channel 2
AIM - Channel 3
AIM - Channel 4
AIM - Channel 5
AIM - Channel 6
AIM - Channel 7
AIM - Channel 8
AIM - Channel 9
AIM - Channel 10
- - TRM - Channel 1 Reference channel for phase angle
presentation
Table 2: TRM_6I_4U Non group settings (basic)
Name
Values (Range) Unit Step Default Description
CTStarPoint1 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTsec1 0.1 - 10.0 A 0.1 1 Rated CT secondary current
CTprim1 1 - 99999 A 1 1000 Rated CT primary current
CTStarPoint2 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTsec2 0.1 - 10.0 A 0.1 1.0 Rated CT secondary current
CTprim2 1 - 99999 A 1 1000 Rated CT primary current
CTStarPoint3 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTsec3 0.1 - 10.0 A 0.1 1 Rated CT secondary current
CTprim3 1 - 99999 A 1 1000 Rated CT primary current
CTStarPoint4 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTsec4 0.1 - 10.0 A 0.1 1.0 Rated CT secondary current
CTprim4 1 - 99999 A 1 1000 Rated CT primary current
CTStarPoint5 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTsec5 0.1 - 10.0 A 0.1 1 Rated CT secondary current
CTprim5 1 - 99999 A 1 1000 Rated CT primary current
Table continues on next page
1MRK 502 048-UEN A Section 3
Analog inputs
47
Technical manual
