9.2.3 Function block

IEC09000278-2-en.vsd

OV2PTOV

U3P*

BLOCK

BLKST1

BLKST2

TRIP

TR1

TR2

START

ST1

ST1L1

ST1L2

ST1L3

ST2

IEC09000278 V2 EN

Figure 133: OV2PTOV function block

9.2.4 Signals

Table 160: OV2PTOV Input signals

Name Type Default Description

U3P GROUP

SIGNAL

- Three phase group signal for voltage inputs

BLOCK BOOLEAN 0 Block of function

BLKST1 BOOLEAN 0 Block of step 1

BLKST2 BOOLEAN 0 Block of step 2

Table 161: OV2PTOV Output signals

Name

Type Description

TRIP BOOLEAN General trip signal

TR1 BOOLEAN Trip signal from step 1

TR2 BOOLEAN Trip signal from step 2

START BOOLEAN General start signal

ST1 BOOLEAN Start signal from step 1

ST1L1 BOOLEAN Start signal from step 1 phase L1

ST1L2 BOOLEAN Start signal from step 1 phase L2

ST1L3 BOOLEAN Start signal from step 1 phase L3

ST2 BOOLEAN Start signal from step 2

Section 9 1MRK 502 048-UEN A

Voltage protection

264

Technical manual
