14.20.3 Signals
Table 437: I103AR Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of status reporting
16_ARACT BOOLEAN 0 Information number 16, auto-recloser active
128_CBON BOOLEAN 0 Information number 128, circuit breaker on by auto-
recloser
130_BLKD BOOLEAN 0 Information number 130, auto-recloser blocked
14.20.4 Settings
Table 438: I103AR Non group settings (basic)
Name Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
14.21 Function status earth-fault for IEC 60870-5-103
I103EF
14.21.1 Functionality
I103EF is a function block with defined functions for earth fault indications in monitor
direction. This block includes the FunctionType parameter, and the information
number parameter is defined for each output signal.
14.21.2 Function block
IEC10000290-1-en.vsd
I103EF
BLOCK
51_EFFW
52_EFREV
IEC10000290 V1 EN
Figure 279: I103EF function block
14.21.3 Signals
Table 439: I103EF Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of status reporting
51_EFFW BOOLEAN 0 Information number 51, earth-fault forward
52_EFREV BOOLEAN 0 Information number 52, earth-fault reverse
Section 14 1MRK 502 048-UEN A
Monitoring
578
Technical manual
